The journal file ( model_database_ name.jnl) For more information, see What is an Abaqus/CAE model database?. The model database file contains models and analysis jobs. When you select File Save from the main menu bar and save the model database, Abaqus/CAE saves the following files: The model database file ( model_database_ name.cae) For more information, see Replaying an Abaqus/CAE session. "c:\Program Files (x86)\Microsoft Visual Studio 9.0\VC\bin\x86_amd64\vcvarsx86_amd64.bat" & "c:\Program Files (x86)\Intel\Compiler\11.1\072\bin\intel64\ifortvars_intel64.bat" & & C:\SIMULIA\ Abaqus\Commands\abq6121.The replay file contains Abaqus/CAE commands that record almost every modeling operation you perform during a session. Start -> Programs -> Abaqus -> Abaqus CAE -> Right click-> Properties If you got all what you needed "PASS" then you can do the same thing to the ABAQUS CAE "verify.log" in ABAQUS default temporary folder to see it. Alternatively you can open the summary file
(You might need to cut off the part || notepad.exe verify.log which to call notepad to open verify.log file when finish as the command is too long)ĭuring the verification process, you would be able to see if all requirements are PASSED or not. "c:\Program Files (x86)\Microsoft Visual Studio 9.0\VC\bin\x86_amd64\vcvarsx86_amd64.bat" & "c:\Program Files (x86)\Intel\Compiler\11.1\072\bin\intel64\ifortvars_intel64.bat" & C:\SIMULIA\Abaqus\Commands\abq6121.bat -verify -all -log & notepad.exe verify.log Please note that if your system is 32 bit or your installed folder not the same then you should change the link accordingly. Start -> Programs -> Abaqus -> Abaqus Verification -> Right click on PropertiesĬ:\SIMULIA\Abaqus\Commands\abq6121.bat -verify -all -log & notepad.exe verify.log || notepad.exe verify.logĪdd the path of the files vcvarsx86_amd64.bat in VS and ifortvars_intel64.bat from Compiler to that: If you check all of those in good order, you can proceed with next steps: I used to have newer versions of VS and Intel Compiler installed and end up with re-install the whole thing to older versions to get them work with ABAQUS. You must make sure the versions of those packages supported by the version of your ABAQUS, otherwise, it never works. I have not upgraded to ABAQUS 6.13 yet so not sure which version of Visual Studio and Intel Compiler are supported now. I used to have too much trouble with linking ABAQUS with Fortran, the main reason is I used NOT compatible versions between them.
